Better and Less YAML with Reuse™

Flexible Horseshoe Card layouts can grow quickly. When building larger cards myself, I often ended up with a lot of repeated YAML. Many items used the same positions, styles, colors, or layout rules, while only one or two fields changed.

That made the configuration harder to read and slower to update. A small visual change could mean editing the same value in several places.

Reuse™ was added to make that easier.

Instead of repeating full YAML blocks, you define the shared part once and reuse it wherever needed. The card expands this into a complete internal configuration before rendering. The rendered result is the same, but the external YAML stays shorter, cleaner, and easier to maintain.

For practical card examples, see Card Examples.

The problem

A common layout pattern is a small group of repeated items. In this example, the card contains three horizontal lines with the same position logic, length, and style.

Without reuse, the same values must be repeated for every line:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
hlines:
  - xpos: 50
    ypos: 64
    length: 85
    styles:
      stroke: var(--disabled-text-color)
      stroke-width: 2

  - xpos: 50
    ypos: 75 # 11 lower than previous hline
    length: 85
    styles:
      stroke: var(--disabled-text-color)
      stroke-width: 2

  - xpos: 50
    ypos: 86 # 11 lower than previous hline
    length: 85
    styles:
      stroke: var(--disabled-text-color)
      stroke-width: 2

This works, but it is not ideal while designing a card. If the length, style, starting position, or spacing changes, you have to update the same values in multiple places.

YAML anchors can reduce some duplication:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
hlines:
  - &hline_base
    xpos: 50
    ypos: 64
    length: 85
    styles:
      stroke: var(--disabled-text-color)
      stroke-width: 2

  - <<: *hline_base
    ypos: 75

  - <<: *hline_base
    ypos: 86

However, anchors are not a complete solution:

  • YAML anchors cannot calculate repeated spacing.
  • Anchor names must be unique across the entire YAML file.
  • The syntax is harder for many users to read.
  • Overriding values can cause duplicate-key warnings in the Home Assistant YAML loader.

Example duplicate-key warning:

Logger: annotatedyaml.constructors
Source: util/yaml/loader.py:65

YAML file /config/lovelace/views/whatever.yaml contains duplicate key "ypos".

That is why the card includes its own reuse system.

The Reuse™ approach

The same three lines can be written as one base line and two reused lines:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
constants:
  lineStep: 11
  defaultLineStyle:
    stroke: var(--disabled-text-color)
    stroke-width: 2

hlines:
  - id: first
    xpos: 50
    ypos: 64
    length: 85
    styles: ref(defaultLineStyle)

  - id: second
    same_as: first
    same_as_dypos: calc(1 * lineStep)

  - id: third
    same_as: first
    same_as_dypos: calc(2 * lineStep)

This keeps the pattern easy to see:

Item Meaning Result
first Base line ypos: 64
second Same as first, 1 step lower ypos: 75
third Same as first, 2 steps lower ypos: 86

Internally, the card expands this into full items before rendering:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
hlines:
  - id: first
    xpos: 50
    ypos: 64
    length: 85
    styles:
      stroke: var(--disabled-text-color)
      stroke-width: 2

  - id: second
    xpos: 50
    ypos: 75
    length: 85
    styles:
      stroke: var(--disabled-text-color)
      stroke-width: 2

  - id: third
    xpos: 50
    ypos: 86
    length: 85
    styles:
      stroke: var(--disabled-text-color)
      stroke-width: 2

The external configuration stays compact. The internal configuration is still complete.

Main features

Feature Purpose
same_as Reuse an earlier item from the same section
same_as_d... Reuse an item and add a numeric offset
constants Define reusable static values or configuration fragments
calc() Use static calculations in numeric fields. Required to use constants
ref() Copy a value from constants into the configuration

All of these are static configuration features. They are processed during card setup, not during every render.

Reusing items with same_as

same_as copies an earlier item from the same section.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
circles:
  - id: base
    xpos: 50
    ypos: 50
    radius: 40
    styles:
      stroke: red
      fill: none

  - id: smaller
    same_as: base     # reuse base
    radius: 30        # ..but with smaller radius
    styles:           # ..and different styles
      stroke: blue
      fill: none

The smaller circle copies xpos and ypos from base, but overrides radius and styles.

Automatic ids or named ids

For reuse to work, each item in a section should have a unique id. There are two options.

Each item can have an explicit id:

1
2
3
4
5
6
7
8
9
hlines:
  - id: first
    xpos: 50
    ypos: 64
    length: 85

  - id: second
    same_as: first    # reuse first
    ypos: 75

If no id is defined, the card automatically assigns one based on the item index:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
hlines:
  - xpos: 50
    ypos: 64
    length: 85

  - same_as: 0        # reuse item with index 0
    ypos: 75          # and modify ypos

  - same_as: 0        # reuse item with index 0
    ypos: 86          # and modify ypos

same_as: 0 and same_as: "0" both refer to the first item.

Automatic ids are fine for short examples. For larger card configurations, named ids are usually easier to understand.

Delta fields

A reused item can override a field directly:

1
2
3
4
5
6
7
8
9
hlines:
  - id: first
    xpos: 50
    ypos: 64
    length: 85

  - id: second
    same_as: first      # Reuse first
    ypos: 75            # set ypos to hard coded value of 75

For repeated numeric changes, a delta field is often clearer:

1
2
3
4
5
6
7
8
9
hlines:
  - id: first
    xpos: 50
    ypos: 64
    length: 85

  - id: second
    same_as: first      # Reuse first
    same_as_dypos: 11   # but use delta from first ypos value

A delta field uses this pattern:

same_as_d<field>: <number>

The delta is added to the inherited value.

Delta field Target field Meaning
same_as_dxpos xpos Add to the inherited xpos
same_as_dypos ypos Add to the inherited ypos
same_as_dlength length Add to the inherited length
same_as_dradius radius Add to the inherited radius

The pattern is generic. You can use same_as_d<field> with any inherited numeric field.

Example with circles:

1
2
3
4
5
6
7
8
9
circles:
  - id: outer
    xpos: 50
    ypos: 50
    radius: 40

  - id: inner
    same_as: outer      # Reuse outer
    same_as_dradius: -5 # but with smaller radius

Result: inner.radius becomes 35.

Static calculations with calc() and constants

YAML itself does not calculate values. So the next line is nothing more than text, not a formula

1
xpos: 50 - 4

Use calc() when a numeric value should be calculated during card setup.

This makes the intent clear: both icons are placed around the center point.

1
2
3
4
5
6
7
8
icons:
  - id: left
    xpos: calc(50 - 4)
    ypos: 50

  - id: right
    xpos: calc(50 + 4)
    ypos: 50

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
constants:
  iconOffset: 4
layout:
  icons:
    - id: left
      xpos: calc(50 - iconOffset)
      ypos: 50

    - id: right
      xpos: calc(50 + iconOffset)
      ypos: 50

Result in both cases:

Item Calculation Result
left xpos: calc(50 - 4) xpos: 46
right xpos: calc(50 + 4) xpos: 54

Static only

calc() is evaluated once during configuration setup. It is not a JavaScript template and is not evaluated during runtime updates.

Constants and ref()

Use constants for shared static values or configuration fragments.

Use ref() to copy one of those constants into the configuration.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
constants:
  centerX: 50
  iconOffset: 4
  lineStyle:
    stroke: var(--disabled-text-color)
    stroke-width: 2

icons:
  - id: left
    xpos: calc(centerX - iconOffset)
    ypos: 50

  - id: right
    xpos: calc(centerX + iconOffset)
    ypos: 50

hlines:
  - id: divider
    xpos: ref(centerX)
    ypos: 64
    length: 85
    styles: ref(lineStyle)

This keeps shared values in one place.

If the center position, icon spacing, or line style changes later, you only need to update the constant.

Chained reuse or one base item

There are two useful ways to create repeated items.

Use one base item when every item follows a fixed pattern from the same source:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
constants:
  centerX: 50
  lineStep: 11
layout:
  hlines:
    - id: first
      xpos: calc(centerX)
      ypos: 64
      length: calc(4 * 20 + 5)

    - id: second
      same_as: first
      same_as_dypos: calc(1 * lineStep)

    - id: third
      same_as: first
      same_as_dypos: calc(2 * lineStep)

This means:

second = first + 1 step
third  = first + 2 steps

Use chained reuse when each item builds on the previous item:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
constants:
  centerX: 50
  lineStep: 11
layout:
  hlines:
    - id: first
      xpos: calc(centerX)
      ypos: 64
      length: calc(4 * 20 + 5)

    - id: second
      same_as: first
      same_as_dypos: calc(lineStep)

    - id: third
      same_as: second
      same_as_dypos: calc(lineStep)

This means for ypos:

second = first + 11
third  = second + 11

For fixed grids or repeated spacing, reusing one base item is often clearer. For progressive changes, chained reuse can be more compact.

Larger items: horseshoes

Reuse becomes more valuable when the repeated item is larger.

A simple line only has a few fields. A horseshoe can contain scale settings, state settings, tick marks, labels, colors, widths, minimum and maximum values, and display options.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
constants:
  defaultColorStops:
    0: '#49ce4b'    # ligh green
    50: '#fed125'   # yellow
    100: '#e9343d'  # red

horseshoes:
  - id: base
    group: base
    radius: 45
    horseshoe_scale:
      min: 0
      max: 100
      width: 6
    horseshoe_state:
      width: 8
    show:
      horseshoe: true
      ticks: true
    color_stops: ref(defaultColorStops)

  - id: power
    group: power
    same_as: base
    entity_index: 1
    color_stops: ref(powerColorStops)
    horseshoe_scale:
      min: 0
      max: 5000

  - id: temperature
    group: temperature
    same_as: base
    entity_index: 2
    color_stops: ref(temperatureColorStops)
    horseshoe_scale:
      min: -10
      max: 40

Only the differences are shown in the reused horseshoes. The shared visual setup stays in base.

Bigger repeated blocks benefit the most

Reusing a three-line block saves a little YAML. Reusing a horseshoe with nested settings can save a lot of YAML and makes later changes much safer.

When to use reuse

Use reuse when a layout has a clear pattern:

  • repeated lines, circles, icons, names, or states
  • multiple horseshoes with the same visual setup
  • shared styles or color stops
  • fixed spacing between items
  • positions calculated from a shared center point
  • several values derived from one constant

Do not use reuse everywhere. For a single unique item, normal YAML is often clearer.
